Description:
- 5-MP 1/2.7" CMOS image sensor, low luminance, and high definition image.
- Outputs max. 5MP (2960×1668) @25/30 fps.
- Built-in IR LED, and the max. illumination distance is 60 m.
- ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
- With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
- Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
- 12 VDC/PoE power supply; ePoE.
- IP67 and IK10 protection.
- SMD 3.0.
Vendor Homepage: www.dahuasecurity.com/ne/products/All-Products/Network-Cameras/WizMind-S-Series/5MP/IPC-HFW5541E-ZE-S3=S3
Category Code: FNC
CnCode: 85258900
Unit Box Height: 0.135
Unit Box Length: 0.365
Unit Box Width: 0.15
Alarm In: 2
Alarm Out: 1
Audio-In: 1
Audio-Out: 1
RJ45: 1
Model: IPC-HFW5541E-ZE-27135-S3
Camera design: Bullet
Network Camera Type: Outdoor
Resolution: 5
IR Illumination: Yes
Sensor size: 1/2.7″ CMOS
Microphone: Built-in
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Power options: 12V/PoE
Power supply requirements: 12 VDC/PoE (802.3af)/ePoE
Environment: Outdoor
Operating temperature range: –30 °C to +60 °C
Dimensions: –30 °C to +60 °C
Units per Shipping Box: 4
Unit Calculated Volume: 0.009127
Product Net Weight: 1.12
Unit Calculated Weight: 1.79
