Mainboard ASROCK Intel Z790 LGA1700 ATX Memory DDR5 Memory slots 4 3xPCI-Express 3.0 1x 1xPCI-Express 4.0 16x 1xPCI-Express 5.0 16x 4xM.2 1xHDMI 1xAudio-In 1xAudio-Out 1xMicrophone 1xUSB 2.0 6xUSB 3.2 1xUSB-C 1xRJ45 Z790PGLIGHTNING

Description:

– Supports 13th Gen & 12th Gen Intel® Core™ Processors
– 14+1+1 Phase Power Design, Dr.MOS for VCore+GT
– 4 x DDR5 DIMMs, supports up to 6800+(OC)
– 1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 3 PCIe 3.0 x1, 1 M.2 Key-E for WiFi
– Graphics Output Options: 1 HDMI, eDP
– 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio
– 1 Hyper M.2 (PCIe Gen4x4 & SATA3), 3 Hyper M.2 (PCIe Gen4x4), 4 SATA3
– 1 USB 3.2 Gen2x2 Type-C (Rear), 1 USB 3.2 Gen2 Type-A (Rear), 1 USB 3.2 Gen1 Type-C (Front), 9 USB 3.2 Gen1 Type-A (5 Rear, 4 Front), 3 USB 2.0 (1 Rear, 2 Front)
– Realtek 2.5G LAN

Vendor Homepage: www.asrock.com/mb/Intel/Z790%20PG%20Lightning/index.asp
Category Code: MBI
CnCode: 84733020
Unit Box Height: 0.075
Unit Box Length: 0.355
Unit Box Width: 0.305
M.2: 4
PCI-Express 3.0 1x: 3
PCI-Express 4.0 16x: 1
PCI-Express 5.0 16x: 1
Audio-In: 1
Audio-Out: 1
HDMI: 1
Microphone: 1
RJ45: 1
USB 2.0: 1
USB 3.2: 6
USB-C: 1
SATA: Yes
USB 2.0: Yes
USB 3.2: Yes
Model: Z790 PG LIGHTNING
Chipset: Intel Z790
Socket: LGA1700
Form Factor: ATX
Memory type: DDR5
Frequency speed: 6800
Memory slots: 4
Integrated video: Depending on CPU
Integrated LAN: Gigabit
Integrated audio: Realtek ALC897
RAID: SATA 0, 1, 5, 10; NVMe 0, 1, 5
TPM: Header
Included Accessories: – 1 x User Manual
– 2 x SATA Data Cables
– 5 x Screws for M.2 Sockets
– 1 x Standoff for M.2 Socket
Units per Shipping Box: 1
Unit Calculated Volume: 0.008121
Product Net Weight: 1.1
Unit Calculated Weight: 1.47
