Mainboard ASROCK Intel Z790 LGA1700 ATX Memory DDR5 Memory slots 4 2xPCI-Express 3.0 1x 1xPCI-Express 4.0 16x 1xPCI-Express 5.0 16x 4xM.2 1xHDMI 1xDisplayPort 4xUSB 2.0 3xUSB 3.2 1xUSB-C 1xPS/2 1xRJ45 3xAudio port Z790PRORS

Description:

• Supports 13th Gen & 12th Gen Intel® Core™ Processors
• 14+1+1 Phase Power Design, Dr.MOS for VCore+GT
• 4 x DDR5 DIMMs, supports up to 6800+(OC)
• 1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 2 PCIe 3.0 x1, 1 M.2 Key-E for WiFi
• Graphics Output Options: 1 HDMI, 1 DisplayPort, eDP
• 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio
• 4 Hyper M.2 (PCIe Gen4x4), 8 SATA3
• 1 USB 3.2 Gen2x2 Type-C (Front), 1 USB 3.2 Gen2 Type-C (Rear), 1 USB 3.2 Gen2 Type-A (Rear), 6 USB 3.2 Gen1 (2 Rear, 4 Front), 8 USB 2.0 (4 Rear, 4 Front)
• Realtek 2.5G LAN

Vendor Homepage: www.asrock.com/mb/Intel/Z790%20Pro%20RS/index.asp
Category Code: MBI
CnCode: 84733020
Unit Box Height: 0.095
Unit Box Length: 0.38
Unit Box Width: 0.32
M.2: 4
PCI-Express 3.0 1x: 2
PCI-Express 4.0 16x: 1
PCI-Express 5.0 16x: 1
Audio port: 3
DisplayPort: 1
HDMI: 1
PS/2: 1
RJ45: 1
USB 2.0: 4
USB 3.2: 3
USB-C: 1
SATA: Yes
USB 2.0: Yes
USB 3.2: Yes
Model: Z790 Pro RS
Chipset: Intel Z790
Socket: LGA1700
Form Factor: ATX
Memory type: DDR5
Frequency speed: 6800
Memory slots: 4
Integrated video: Depending on CPU
Integrated LAN: 2.5 Gigabit
Integrated audio: Realtek ALC897
RAID: SATA 0, 1, 5, 10; NVMe 0, 1, 5, 10
TPM: Header
Included Accessories: – 1 x User Manual;
– 2 x SATA Data Cables;
– 5 x Screws for M.2 Sockets;
– 1 x Standoff for M.2 Socket
Units per Shipping Box: 1
Unit Calculated Volume: 0.01155
Product Net Weight: 1.5
Unit Calculated Weight: 1.98
